Key Features
- IS 694:2016 Certified BIS approved - highest Indian quality standards
- Multiple Core Options: 2-core, 3-core, 4-core, 5-core configurations
- Wide Size Range: 0.5 mm2 to 120 mm2 conductor sizes
- Pure Copper Conductor 99.9% copper for superior conductivity
- PVC Insulation & Sheath:Flame-retardant, weather-resistant outer sheath
- Flexible Design:Class 2 & Class 5 conductor options for flexibility
- 1 kV Rated:Suitable for 415V 3-phase and 230V single-phase systems
- Cost-Effective:Excellent value for industrial and domestic applications
Technical Specifications
Conductor & Insulation
| Parameter | Specification |
|---|---|
| Conductor Material | Bare Copper - 99.9% Pure (IEC 60228) |
| Conductor Class | Class 1 (Solid) & Class 2/5 (Stranded - Flexible) |
| Conductor Size | Range 0.5 mm2 to 400 mm2 |
| Number of Cores | 2-core, 3-core, 4-core, 5-core and above. |
| Core Identification | Color-coded per IS 694 (Brown, Black, Red, Grey, Blue) |
Insulation & Sheath Specifications
| Parameter | Specification |
|---|---|
| Insulation Material | PVC (Polyvinyl Chloride) - Flame Retardant |
| Insulation Thickness | 0.5-1.5 mm (varies by conductor size per IS 694) |
| Outer Sheath Material | PVC (Polyvinyl Chloride) - Flame Retardant |
| Sheath Thickness | 0.5-1.5 mm (varies by conductor size) |
| Rated Voltage | 1 kV AC (1000 V) |
| Nominal Voltage | 230V / 415V (Suitable for LT distribution) |
Electrical Properties.
| Parameter | Value/ Specification |
|---|---|
| Insulation Resistance | Min. 100 MW @ 20°C (per 100 m of cable) |
| Dielectric Strength | Min. 2 kV for 1 minute (per IS 694)/td> |
| Tensile Strength Min. 15 MPa | Min. 12 MPa (PVC Insulation) |
| Elongation at Break | Min. 100% |
| Resistance @ 20°C | 1.5 mm2: 12.1 W/km | 16 mm2: 1.15 W/km |
| Operating Temp | -5°C to +70°C (Continuous) |
| Short Circuit Limit | +100°C (Emergency limit - 5 seconds) |
Environmental & Safety Properties
| Parameter | Specification |
|---|---|
| Flame Retardancy | IS 7098 - Vertical Flame Test (No propagation) |
| Smoke Density | ASTM D2843 - Low smoke emission |
| Temperature Range | Storage: -10°C to +55°C (dry condition) |
| Weather Resistance | Suitable for indoor and outdoor use |
| Water Absorption | Max. 1% after 24 hrs immersion |
| Ozone Resistance | Resistant to ozone degradation |
CONDUCTOR SIZE SPECIFICATIONS & DIMENSIONS
VITA Multi-Core PVC Cable is available in the following conductor cross-sections: from 0.5 sqmm upto 400sqmm.
Typical Dimensions & Weights (2-Core Cable)
| Cross Section (Sqmm) | Appx Outer Diameter (mm) | Weight (Kg/km) | Min. Bending Radius (mm) |
|---|---|---|---|
| 0.5 | 5.0 | 25 | 20 |
| 1.0 | 5.5 | 38 | 25 |
| 1.5 | 6.0 | 55 | 30 |
| 2.5 | 6.8 | 92 | 35 |
| 4.0 | 7.8 | 148 | 40 |
| 6.0 | 9.8 | 221 | 50 |
| 10.0 | 10.8 | 368 | 60 |
| 16.0 | 13.0 | 588 | 75 |
| 25 | 15.5 | 920 | 90 |
| 35 | 18.0 | 1288 | 110 |
| 50 | 20.5 | 1840 | 130 |
| 70 | 23.5 | 2576 | 150 |
| 95 | 27.0 | 3484 | 180 |
| 120 | 30.0 | 4416 | 200 |
Note: Dimensions increase proportionally for 3-core, 4-core, and 5-core cables. Contact VITA for specific dimensions.
STANDARDS & CERTIFICATIONS
VITA Multi-Core PVC Cable is manufactured and tested in strict compliance with the following standards:
| Standard/Certifications | Description |
|---|---|
| IS 694:2016 | Multi-core PVC insulated unarmored cables rated up to 1100 V (India) |
| IEC 60227 | PVC insulated cables - Rated voltages up to 450/750 V |
| IEC 60228 | Conductors of insulated cables |
SUITABLE APPLICATIONS
VITA Solar PV Cable is ideal for:
- Power distribution in buildings (residential, commercial, industrial)
- Lighting circuits and appliance connections
- 3-phase motor connections and power supply
- Control circuits and instrumentation wiring
- Temporary and permanent installations
- Distribution boards, panel boards, and sub-station wiring
- Machine tool connections and industrial machinery
- Cable trays and underground duct installations
INSTALLATION & SAFETY GUIDELINES
- Installation:Cable must be installed by qualified electricians. Minimum bending radius is 5 times the cable diameter. UV-protective conduits recommended for exposed outdoor routing. All connections must comply with relevant solar installation codes.
- Storage & Handling:Store in cool, dry environment away from direct sunlight and extreme temperatures. Shelf life: 24 months from manufacturing date (under optimal conditions).
