Key Features
Flame Retardant PVC Insulation (FRLS
grade)
High Copper Purity (99.97%)
Low Smoke Halogen (LSH) Properties
Excellent Flexibility
Superior Durability
BIS Certified & IS/IEC Compliant
Available in all standard sizes (0.5
sqmm to 70 sqmm)
2. Technical Specifications
2.1 Conductor Specifications
| Parameter | Specification | Standard Reference |
|---|---|---|
| Conductor Material | Electrolytic Grade Copper | IS 694:2016 |
| Conductor Type | Stranded (Class 2) | IS 694:2016 |
| Copper Purity | 99.97% minimum | IS 694:2016 |
| Cross-Section Range | 0.5 sqmm to 70 sqmm | --- |
| Number of Strands | Size dependent (7 to 126 wires) | IS 694:2016 |
2.2 Insulation Specifications
| Parameter | Specification | Standard Reference |
|---|---|---|
| Insulation Material | Flame Retardant PVC (FRLS) | IS 694:2016 |
| Insulation Color | Red, Black, Yellow, Green, Blue, White, Brown | IS 694:2016 |
| Flame Retardancy Grade | FRLS (Low Smoke Halogen) | IS 694:2016 |
| Operating Temperature | -5°C to +90°C continuous | IS 694:2016 |
| Insulation Resistance | ≥ MΩ/km at 20°C | IS 694:2016 |
2.3 Voltage & Current Ratings (Per IS 694:2016)
| Cross-Section (sqmm) | Voltage Rating | Current Rating (Amps @ 60°C) | Resistance (Ω/km) |
|---|---|---|---|
| 0.5 | 230V/415V | 6A | 36.0 |
| 1.0 | 230V/415V | 10A | 18.1 |
| 1.5 | 230V/415V | 15A | 12.1 |
| 2.5 | 230V/415V | 20A | 7.41 |
| 4.0 | 230V/415V | 26A | 4.62 |
| 6.0 | 230V/415V | 34A | 3.08 |
| 10 | 230V/415V | 46A | 1.83 |
| 16 | 230V/415V | 61A | 1.15 |
| 25 | 230V/415V | 80A | 0.727 |
| 35 | 230V/415V | 106A | 0.524 |
| 50 | 230V/415V | 134A | 0.387 |
| 70 | 230V/415V | 171A | 0.268 |
Note: Current ratings are based on IS 694:2016 FRLS standard for single core cables in ambient temperature of 30°C with 30°C rise.
Physical Specifications
| Parameter | Specification |
| Outer Diameter Range | 1.5 mm (0.5 sqmm) to 8.5 mm (70 sqmm) |
| Weight Range | 2.5 kg/km (0.5 sqmm) to 180 kg/km (70 sqmm) |
| Minimum Bending Radius | 3 × Outer Diameter (at -5°C) |
| Tensile Strength | ≥ 5 MPa (insulation) |
| Elongation at Break | ≥200% (insulation) |
3. Standards & Certifications
Manufacturing Standards:
- IS 694:2016 Single core PVC insulated cables for rated voltages up to and including 450/750V
- IEC 60227 PVC insulated cables (International Electrotechnical Commission)
- BIS Certified Bureau of Indian Standards certification
- ISO 9001:2015 Quality Management System certified manufacturing
4. Applications
Recommended Uses
- Residential Wiring: Household installations, distribution boards, lighting and power circuits
- Commercial & Office: Building wiring, lighting installations, power distribution
- Light Industrial: Factory wiring, machine control circuits, emergency lighting
- Safety-Critical: Hospitals, schools, fire-rated building sections
