Key Features
- CPRI Certified: Tested and approved by Central Power Research Institute (India).
- UV & Weather Resistant:25+ years outdoor durability
- XLPE Insulation:Superior electrical and mechanical protection
- Flame Retardant:Enhanced fire safety (IEC 60811)
- PVC Outer Sheath:Moisture and dust protection
- Pure Copper:99.9% copper (IEC 60228 Class 6 - Flexible)
- Temperature Rated: -40°C to +90°C (normal), +120°C (emergency)
Technical Specifications
Conductor & Insulation
| Parameter | Specification |
|---|---|
| Conductor Material | Bare Copper - 99.9% Pure (IEC 60228) |
| Conductor Class | Class 6 (Flexible) |
| Conductor Size | 1.5 mm2 to 16 mm2 |
| Insulation Material | XLPE (Cross-linked Polyethylene) |
| Insulation Thickness | 2.0 mm (1.5-6 mm2); 2.5 mm (10-16 mm2) |
| Outer Sheath | PVC (Polyvinyl Chloride) |
| Sheath thickness | 1.5-1.5mm |
| Rated Voltage | 1 KV DC (1000V) |
Electrical Properties.
| Parameter | Value/ Specification |
|---|---|
| Insulation Resistance | Min. 100 MW·km @ 20°C |
| Dielectric Strength | Min. 6 kV (5 min) - CPRI Tested |
| Tensile Strength Min. 15 MPa | Min. 15 MPa |
| Elongation at Break | Min. 150% |
| Resistance @ 20°C | 1.5 mm2: 12.1 W/km | 16 mm2: 1.15 W/km |
| Operating Temp -40°C to +90°C (Continuous) | -20°C to +90°C (Continuous) |
| Short Circuit Limit | +120°C (Emergency - 5 sec max) |
| Dielectric Strength | Min. 6 kV (5 min) - CPRI Tested |
Environmental & Safety Properties
| Parameter | Specification |
|---|---|
| UV Resistance | IEC 60811-2-1 | Min. 5000 hrs to 50% strength |
| Flame | Retardancy IEC 60811-2-2 | No flaming droplets |
| Halogen Content | Halogen-Free (RoHS Compliant) |
| Ozone Resistance | Grade 1 (IEC 60811-2-1) |
| Water Absorption | Max. 0.3% after 24 hrs immersion |
| Weather Life | 25+ years outdoor exposure |
CONDUCTOR SIZE SPECIFICATIONS & DIMENSIONS
| Cross Section (Sqmm) | Conductor Diameter (mm) | Outer Diameter (mm) | Weight (Kg/km) | Min. Breaking Strength (kN) |
|---|---|---|---|---|
| 1.5 | 1.38 | 5.0 | 47 | 0.35 |
| 2.5 | 1.78 | 6.0 | 78 | 0.58 |
| 4.0 | 2.26 | 6.8 | 125 | 0.93 |
| 6.0 | 2.76 | 7.8 | 188 | 1.40 |
| 10.0 | 3.57 | 9.3 | 313 | 2.32 |
| 16.0 | 4.51 | 10.8 | 600 | 3.71 |
STANDARDS & CERTIFICATIONS
VITA Solar PV Cable is manufactured and tested in compliance with the following international standards
| Standard/Certifications | Description |
|---|---|
| IEC 61931 | Test methods for cables in photovoltaic systems |
| IEC 62930 | Cords and cables for photovoltaic installations |
| IEC 60811 | Insulation and sheath test methods |
| IEC 60227 | PVC insulated cables - 450/750 V rated |
| IEC 60228 | Conductors of insulated cables |
| CPRI Certified | Central Power Research Institute (India) approval |
SUITABLE APPLICATIONS
VITA Solar PV Cable is designed for:
- Rooftop Solar PV Systems (Residential & Commercial)
- Grid-Connected & Off-Grid Solar Installations
- Solar Farms & Utility-Scale Power Projects
- DC Wiring in Junction Boxes, Combiner Boxes & Inverters
- Flexible Conduit Routing in Solar Panel Arrays
- Government Tender & Subsidy-Based Solar Projects
- Industrial & Agricultural Solar Applications
INSTALLATION & SAFETY GUIDELINES
- Installation:Cable must be installed by qualified electricians. Minimum bending radius is 5 times the cable diameter. UV-protective conduits recommended for exposed outdoor routing. All connections must comply with relevant solar installation codes.
- Storage & Handling:Store in cool, dry environment away from direct sunlight and extreme temperatures. Shelf life: 24 months from manufacturing date (under optimal conditions).
- 8 WARRANTY & TECHNICAL SUPPORT
- 5-Year Warranty: VITA Cable offers 5-year warranty against manufacturing defects including conductor
- breaks, insulation failures, and sheath degradation under normal operating conditions.
- Technical Support: Contact our technical team for installation guidance and specifications.
